DALI-2 DT8 power supply, 2 outputs

Model number: LCM-40TW

contact person:林簡松 (0920422525)
product categoryhealthy lighting,classroom lighting,hospital lighting,human lighting,office lighting

  • Compliant with IEC 62386 DALI-2, Part 101/102/207(DT6)/209(DT8)
  • Input 180~277V AC, plastic case Class II design (without FG)
  • Output constant current multi-stage adjustable: 500/600/700/800/900/1050 m A
  • With Push dim dimmable/adjustable color temperature function
  • Single or two output groups, DT6 or DT8 application optional
  • DT6 single color temperature adjustable / DT8 dual color temperature adjustable minimum brightness up to 0.2%
  • Lifetime >50,000 hours, five-year warranty


keywordscomply with DALI-2 DT8 adjustable color temperature LED driver
